Specifications & Technical Details
| Camera | ||
|---|---|---|
| Image Sensor: | | | 2MP CMOS Image Sensor |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | 1944(H)×1092(V) |
| Min. Illumination: | | | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Time: | | | 1/25(1/30) s to 1/50,000 s |
| Lens: | | | 3.6mm (6mm optional) Angle of View: 82.6°(3.6mm), 54.4°(6mm) |
| Lens Mount: | | | M12 |
| Adjustment Range: | | | Pan: 0 – 360°, Tilt: 0 – 180°, Rotation: 0 – 360° |
| Day& Night: | | | IR cut filter with auto switch |
| Wide Dynamic Range: | | | 120dB |
| Video Frame Rate: | | | 1080p@25fps/1080p@30fps |
| HD Video Output: | | | 1 Analog HD output |
| Synchronization: | | | Internal Synchronization |
| CVBS Output: | | | 1Vp-p Composite Output(75Ω/BNC) |
| S/N Ratio: | | | More than 62 dB |
| BLC: | | | Support |
| Up the Coax: | | | Support |
| Menu | ||
| Camera ID: | | | On/Off (15 letters, adjusted position) |
| D/N Mode: | | | Color/ BW/ EXT |
| Auto White Balance: | | | ATW/ AWC-SET/ Indoor/ Outdoor/ Manual |
| Private Mask: | | | On/Off, maximum 8 zones |
| Motion Detection: | | | On/Off, maximum 4 zones |
| BLC: | | | BLC/HLC/Off |
| Anti-flicker: | | | On/ Off |
| Language: | | | English/ Japanese/ CHN1/ CHN2/ Korean/ German/ French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish/ Hebrew/ Arabic |
| Function: | | | Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM |
| Scene: | | | Indoor, Outdoor, Indoor1, LOW-LIGHT |
| General | ||
| Operating Conditions: | | | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | | | 12 VDC±15% |
| Power Consumption: | | | Max. 4W |
| Weather Proof: | | | IP66 |
| IR Range: | | | Up to 20m |
| Dimension: | | | Φ70×149.5 mm (Φ2.76” ×5.89”) |
| Weight: | | | 360 g (0.79 lb) |
