Features & Specifications
Lens Size:4mm(default), 2.8mm lens optional
- The camera has POE function and NO Power adapter in the original package.
- Please DO NOT update the camera with any other firmware which is not supplied by the seller. Normally, the firmware installed can’t be upgraded.
- 1MP 1/4” Progressive scan CMOS
- Support dual streams
- Up to 10m IR visibility
- True day/night
- 3D DNR & DWDR & BLC
- -I: PoE
| Camera | |
|
Image Sensor:
|
1/4″ Progressive Scan CMOS |
| Min. Illumination: | 0.01Lux @(F1.2,AGC ON) ,0 Lux with IR 0.028Lux @(F2.0,AGC ON) ,0 Lux with IR |
| Shutter time: | 1/3s ~ 1/100,000 s |
| Slow shutter: | Support |
| Lens: | 4mm@F2.0(2.8mm optional) Angle of view: 73.1°(4mm) |
| Lens Mount: | M12 |
| Adjustment Range: | Pan:0° – 360°, Tilt: 0° – 75°,Rotation: 0-360° |
| Day& Night: | IR cut filter with auto switch |
| Wide Dynamic Range: | Digital WDR |
| Digital noise reduction: | 3D DNR |
| Compression Standard | |
| Video Compression: | H.264/MJPEG |
| H.264 code profile: | BaseLine Profile/Main Profile |
| Video bit rate: | 32Kbps~8Mbps |
| Dual Stream: | Yes |
| Image | |
| Max. Image Resolution: | 1280×720 |
| Frame Rate: | 50Hz: 25fps (1280 × 720) 60Hz: 30fps (1280 × 720) |
| Image Enhancement: | BLC/3D DNR/ROI |
| Image Settings: | Saturation,Brightness,Contrast adjustable by client software or web browser |
| Day/Night Switch: | Auto/Schedule/Triggered by Alarm In |
| Network | |
| Alarm Trigger: | Motion detection,Dynamic analysis,Tampering alarm |
| Protocols: | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,
SMTP,SNMP,IGMP, |
| Security: | flash-prevention, dual streams, heartbeat, mirror, password protection, privacy mask, Watermark |
| System Compatibility: | ONVIF,PSIA,CGI,ISAPI,GB28181 |
| Interface | |
| Communication Interface: | 1 RJ45 10M/100M Ethernet interface |
| General | |
| Operating Conditions: | -10°C~40°C Humidity 95% or less (non-condensing) |
| Power Supply: | 12VDC±10%,PoE(802.3af) |
| Power Consumption: | 3.2W MAX |
| IR Range: | 10M |
| Dimensions(mm): | Φ110 × 80.9 |
| Weight: | 190g |
