C-Data FD511G-X-F361 NETWORKING SWITCH

$4.70

+ Free Shipping
  • Full compatible with IEEE802.3ah
  • Support ONU auto-discovery/Link detection/remote upgrade of software
  • Support MACand LOID+Password multiple registration methods
  • Support port VLAN configuration
  • Support mac-address learning
  • Support port-based rate limitation and bandwidth control
  • Support port flow-control
SKU: TL-SG3210-1-2-1 Categories: , ,
Item Parameters Specification
Interface PON Interface 1 EPON optical interface
Meet 1000BASE-PX20+ standard
Symmetric 1.25Gbps upstream/downstream
SC/PC single-mode fiber
split ratio: 1:64
Transmission distance 20KM
Ethernet Interface 1*10/100/1000M auto-negotiationFull Duplex / Half-Duplex

RJ45 connector

Auto MDI/MDI-X

Transmission Distance 100 Meter
Power Interface 12V DC supply power
Performance Parameters PONOptical

Parameter

 Wavelength: Tx 1310nm, Rx1490nm
Tx Optical Power: 0～4dBm
Rx Sensitivity: -27dBm
Saturation Optical Power: -3dBm
Data Transmission
Parameter		 PON Throughput: Downstream 980Mbps; Upstream 950Mbps
Ethernet: 1000Mbps
Packet Loss Ratio: <1*10E-12 latency: <1.5ms
Network Management Network
Management		 Support IEEE802.3 QAM, ONU can be remotely managed by OLT;Support WEB management
Management
Function		 Status monitor, Configuration management, Alarm management, Log management
Environmental
Specifications		 Shell White plastic casing
Power External 12V/0.5A DC power supply adapterPower consumption: <3W
Dimensions Item Dimension：125mm(L) x80mm(W) x28mm (H)Item weight：0.1kg
Environment Operating Temperature：0～50℃Storage Temperature：-40～85℃

Operating Humidity：10%～90%(Non-condensing)

Storage Humidity：10%～90%(Non-condensing)
Specs

Check product description page for more technical details and specifications
